WBTU1083-N integrated port floodlight
high power port lighting · 400W / 480W · F2 corrosion protection · IP66
high power port lighting · 400W / 480W · F2 corrosion protection · IP66
Aluminum lamp body with symmetrical rear ribbed heat-sink design for high thermal conductivity. Enclosed independent power-supply box structure provides excellent waterproof performance, and the hollow housing design prevents water accumulation. Uses first-tier LED light sources (CREE / OSRAM / LUMILEDS optional) with overall luminous efficacy ≥130 lm/W. Professional optical lens provides precise 30° narrow-beam floodlighting. The lamp body is treated with high-tech coating for F2 (C5-M) corrosion protection. Both the lamp body and driver housing include safety lanyards for dual safety assurance. The mounting bracket includes a precision adjustment plate adjustable from 0° to 90° in 10° steps.
| Luminaire Description | Integrated Port Floodlight |
| Model | WBTU1083-N（400W）/ WBTU1084-N（480W） |
| Rated Voltage | AC 220V - 240V |
| Luminaire Power | 400W / 480W（±10%） |
| Overall Dimensions | 353 × 320 × 365 mm |
| Material | Die-cast aluminum |
| Protection Rating | IP66 |
| Vibration Level | 5G |
| Corrosion Protection Grade | F2（C5-M） |
| Mounting Method | Wall mounting |
| Installation Angle | 0° - 90° (adjustable every 10°) |
| Operating Temperature | -40℃ ~ +85℃ |
| Color Temperature Range | 2700K ~ 6500K (optional) |
| Color Rendering Index (Ra) | ≥70 |
| Color Tolerance (SDCM) | <7 |
| Beam Angle | 30° |
| Luminaire Efficacy | ≥130 lm/W |
| Luminaire Lifetime | 50000 h |
| Input Voltage | AC 220V - 240V |
| LED Brand | CREE / OSRAM / LUMILEDS (optional) |
| LED Driver | Mean Well (other brands can be specified) |
| Power Factor | ≥0.9 |
| Surge Protector | 10KV (optional) |
| Cable Outlet | Lower left (A) / lower right (B) / lower left and right (A+B) |
