WBTU1083- PLC integrated PLC port floodlight
intelligent dimming version · 400W / 480W · F2 corrosion protection · IP66 · 0-10V dimming
intelligent dimming version · 400W / 480W · F2 corrosion protection · IP66 · 0-10V dimming
Used with the intelligent lighting gateway (model MK41000106) and PLC touch scene switch (model MK41000107), it enables remote centralized control, scene linkage, and energy management for port lighting.
Built on the same mold platform as WBTU1083-N, this version adds PLC dimming to the standard version. It supports 0-10V analog dimming and can be fitted with a PLC communication module for remote centralized control. Other structural, protection, and optical parameters are the same as WBTU1083-N.
| Luminaire Description | Integrated PLC Port Floodlight |
| Model | WBTU1083-PLC（400W）/ WBTU1084-PLC（480W） |
| Rated Voltage | AC 220V - 240V |
| Luminaire Power | 400W / 480W（±10%） |
| Overall Dimensions | 353 × 320 × 365 mm |
| Material | Die-cast aluminum |
| Protection Rating | IP66 |
| Vibration Level | 5G |
| Corrosion Protection Grade | F2（C5-M） |
| Mounting Method | Wall mounting |
| Installation Angle | 0° - 90° (adjustable every 10°) |
| Operating Temperature | -40℃ ~ +85℃ |
| Color Temperature Range | 2700K ~ 6500K (optional) |
| Color Rendering Index (Ra) | ≥70 |
| Color Tolerance (SDCM) | <7 |
| Beam Angle | 30° |
| Luminaire Efficacy | ≥130 lm/W |
| Luminaire Lifetime | 50000 h |
| Input Voltage | AC 220V - 240V |
| LED Brand | CREE / OSRAM / LUMILEDS (optional) |
| LED Driver | Mean Well (other brands can be specified) |
| Power Factor | ≥0.9 |
| Dimming Method | 0-10V dimming |
| Surge Protector | 10KV (optional) |
